Mag Bay Yachts 42 2026

2026 Mag Bay Yachts powered by Twin Volvo D13 Engines! Pre-Order Now!

2026 Mag Bay Yachts 42 powered by Twin Volvo D13 Engines!

A NEW LEVEL OF QUALITY ABOARD THE MAG BAY 42’

Features may include:

CONSTRUCTION

• 100% Vinylester Resin Construction.

• Gurit A500 Cored Hull Sides With A Solid Glass Bottom

• Propeller Pockets To Reduce Draft

• Angled Transom Below Waterline To Enhance Maneuverability In Reverse

• Exhaust Exits In Corners Of Boat For Enhanced Performance

• Oversized Fiberglass Encapsulated Full Length Stringer System

• Molded 665 Gallon Fiberglass Fuel Tank With Fiberglass Baffles Integrated Into The Hull

• Modified Rudder Shelf Design To Optimize Space In Aft Lazarette

• Integrated Bilge Pump Shelfs Allow Smooth Operation Of All Bilge Pumps.

• Epoxy Barrier Coat On Hull Below The Waterline

• Integrated Bow Thruster Tunnel With Fairing Built Into The Hull For Unmatched Strength

MECHANICAL

• Oversized Sea Strainers In Aft Lazarette For Washdown And Bait Pumps

• Seastar Eps Electric Hydraulic Steering System Standard.

• Independent Hydraulic Steering Rams Positioned Outboard For Increased Lazarette Access

• Oversized Bilge Pumps Connected To Switches For Automatic And Manual Operation

• Dockside And Overboard Pumpouts For Holding Tank

• Fire Suppression System Automatically Or Manually Operated And Tied Into Main Engine And Generator Ignition Systems With Override

• 24v Fuel Priming Pumps For Main Engines

• Oversized Sea Strainers For Main Engines And Generator

• 'Crash Valve' Off Engine Intakes For Use As Emergency Bilge Pumps

• In-line Mufflers On Vibration And Sound Dampening Mounts With Surge Tube In Engine Room.

• Oil Change System Pump For Main Engines, Transmissions, And Generator With Pump Out Line

ELECTRICAL

• 24v Dc Throughout

• 12v And 24 Power Supply With Breakers For Future Electronics And Systems

• Battery Banks In Fully Accessible Fiberglass Box

• Battery Charger With Thermal Cutoff And Integrated Switching System

• Battery Distribution Panel With Cutoff And Breakers Mounted In Engine Room

• Battery Parallel System For Main Engines And Generator Start

• Color Coded, Numbered And Labeled Wiring Throughout With Accompanying Diagrams

COCKPIT

• Fresh And Saltwater Washdown Spigots

• Glendinning Hose Reels With 20' Hose For Fresh And Saltwater Washdowns In Cockpit

• Oversized Lazarette Hatch With Ample Access To Aft Bilge And Rudder Shelf

• Full Round Rubber Gasket On All Lids And Access Doors

• Laminated Oversized Garolite Plate In Cockpit For Future Fighting Chair Or Pedestal

• Flush Mounted And Screwless Gemlux Rod Holders (4) In Coaming.

• 316 Stainless Gas Pistons On All Lids

• Two Thin Mounted Stereo Speakers Under Gunnel

• Two Oversized 73.5 Gallon Insulated In Deck Fishboxes With Independent Macerator Pumps

HELM DECK

• Controls: Tournament Lever Controls Mounted On Fiberglass Helm Pod

• Electronic Trolling Valves

• Electric Hydraulic Fully Adjustable Steering

• Fire System With Automatic And Manual Discharge With Control On Console

• Engine Manufacturer Supplied Gauges And Electronics

• Helm Console Mounted On Actuator For Full Access To Necessary Systems

• Triple Helm Seat Configuration With Fully Adjustable And Rotating Seats.

www.grandermarine.com | (251) 271-0166
